LASE EP200 w/DSP Amplifier Module Replacement for EV 10P,12P,15P Powered Speaker (110V)
Product details
| Management number | 221445569 | Release Date | 2026/05/03 | List Price | US$88.00 | Model Number | 221445569 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Replacement Amplifier Module LASE - EP200 for Electro Voice EV - ELX 200 -10P;ELX200-12P;ELX200-15P. Bi-Amped Professional Loudspeaker Power-Amplifier Module With DSP Control.(8Ω Load Only). Very Easy To Install. LASE - EP200 Professional Loudspeaker Bi-Amped Power-Amplifier Module is a Replacement for ELX 200 -10P,12P & 15P Powered speaker has a number of unique control features - push button mic/line level inputs,mix level XLR output ,DSP (digital signal processor) on the master control with push button control. Works 110V or 220V
- Power rated @ 8 Ohm Load Only. Output Power : 20-20kHz, 1W with 1 khz Power Output RMS : 500 W RMS, 1000 W peak (overall) @ 8Ω. 400 W RMS, 800 W peak (LF) 100 W RMS, 200 W peak (HF)
- Frequency Response(+o/-0.3dB,1W/8Ω) : 20 Hz - 34 kHz Crossover Frequency : 1.7 Khz THD : 20 Hz - 20 kHz for 1 W <0.1% Signal-to-Noise Ratio : >112 dBA
- Channel separation : (Crosstalk) at 1 kHz >70 dB Input Connectors (per channel) : 3-pin XLR, 1/4" phono, electronically balanced. Output Connector (Mix Out) : 3-pin XLR, electronically balanced Class : D Operating voltage : 220 V / 110 V nominal 190-240 V / 90-130 V selectable
| UPC | 810175751757 |
|---|---|
| Model | 110V |
| Brand Name | LASE |
| Unit Count | 1.0 Count |
| Part Number | EKX12P/15P |
| Manufacturer | LASE |
| Output Power | 500 Watts |
| Mounting Type | Freestanding |
| Number of Channels | 2 |
| Included Components | Amplifer Module |
| Maximum Supply Voltage | 240 Volts |
